1) Provided with stainless steel S.S 304 contact parts (SS 316 optionally)
2) Blower fan is dynamically balanced.
3) Machine in fitted with the castor wheels for easy mobility.
4) Overcome dust hazards as well as cross contamination at tablet compression.
5) Minimizes mechanical strain, excessive wear of tableting machine resulting in minimum machine breakdowns and punch wears.
6) All inlet manifolds and dust collection trays are of S.S. 304
7) Inlet manifolds facilitate to connect any Tablet press machine and De-burring units.
| Suction Capacity | 150 C.F.M. (500 m3 / hr) at 125 mm W.G. |
| Filteration Area | 0.8 sq mtr (approx) |
| Dust Storage Capacity | 20 Lts. |
| Manifolds | mm 02 |
| Power | 0.75 HP / 2880 RPM / 3 Phase / 440 V / 50 Hz |
| Overall Dimensions | 520 x 460 x 700 H |
| Case Dimensions | 600 x 500 x 750 H |
| Net Weight | 90 Kgs. |
| Gross weight | 115 Kgs. |
| Suction Capacity | 300 C.F.M. (500 m3 / hr) at 125 mm W.G. |
| Filteration Area | 1.343 m2 |
| Storage | 40 Lts. |
| Inlet Manifolds (Three) | Dia 60 mm 01 Nos. Dia 38 m 2 Nos. |
| Power | 1.5 HP / 2880 RPM / 3 Phase / 440 V / 50 Hz |
| Overall Dimensions | 620 x 780 x 1270 H |
| Case Dimensions | 790 x 990 x 1670 H |
| Net Weight | 130 Kgs. |
| Gross weight | 200 Kgs. |
1) Provided with stainless steel S.S 304 contact parts (SS 316 optionally)
2) Blower fan is dynamically balanced.
3) Machine in fitted with the castor wheels for easy mobility.
4) Overcome dust hazards as well as cross contamination at tablet compression.
5) Minimizes mechanical strain, excessive wear of tableting machine resulting in minimum machine breakdowns and punch wears.
6) All inlet manifolds and dust collection trays are of S.S. 304
7) Inlet manifolds facilitate to connect any Tablet press machine and De-burring units.
